冰川冻土 ›› 2022, Vol. 44 ›› Issue (2): 535-544.doi: 10.7522/j.issn.1000-0240.2022.0057

• 寒区工程与灾害 • 上一篇

衬砌粗糙度对季节冻土区渠基土-衬砌接触面间峰值抗剪强度的影响

马小涵1,2(), 薛珂1(), 高樯3, 张明礼4, 刘建平1, 谢军1, 向卿2, 杨明东2

  1. 1.四川农业大学 水利水电学院,四川 雅安 625000
    2.四川农业大学 环境学院,四川 成都 611130
    3.中国科学院 西北生态环境 资源研究院 冻土工程国家重点实验室,甘肃 兰州 730000
    4.兰州理工大学 土木工程学院,甘肃 兰州 710050
  • 收稿日期:2022-02-22 修回日期:2022-03-20 出版日期:2022-04-30 发布日期:2022-06-10
  • 通讯作者: 薛珂 E-mail:963073641@qq.com;tumuxk@163.com
  • 作者简介:马小涵,博士研究生,主要从事农业水土环境及气候变化方面研究. E-mail: 963073641@qq.com
  • 基金资助:
    国家自然科学基金项目(41907242)

Impact of lining roughness on peak shear strength of soil-lining interface in seasonal frozen zone

Xiaohan MA1,2(), Ke XUE1(), Qiang GAO3, Mingli ZHANG4, Jianping LIU1, Jun XIE1, Qing XIANG2, Mingdong YANG2

  1. 1.College of Water Conservancy and Hydropower Engineering, Sichuan Agricultural University, Ya’an 625000, Sichuan, China
    2.College of Environment, Sichuan Agricultural University, Chengdu 611130, China
    3.State Key Laboratory of Frozen Soil Engineering, Northwest Institute of Eco-Environment and Resources, Chinese Academy of Sciences, Lanzhou 730000, China
    4.School of Civil Engineering, Lanzhou University of Technology, Lanzhou 710050, China
  • Received:2022-02-22 Revised:2022-03-20 Online:2022-04-30 Published:2022-06-10
  • Contact: Ke XUE E-mail:963073641@qq.com;tumuxk@163.com

摘要:

目前来看,在构筑物与土体表面粗糙度影响土-构筑物接触面间切向冻胀力方面的研究还较少,因此,本研究从川西季节冻土区渠基土-衬砌接触面的切向冻胀力问题出发,着重考虑衬砌表面粗糙度这一因素对接触面间抗剪强度、黏聚力、内摩擦角的影响规律和影响效应,并结合环境温度、含水率及冻结时长,利用正交分析综合探究了4种因素对接触面间峰值抗剪强度影响的相关性和显著性,结果表明:接触面间抗剪强度、黏聚力、内摩擦角随衬砌表面粗糙度变化呈现相同规律,即衬砌表面越粗糙,3项指标随即增大。正交分析中揭示了影响接触面间峰值抗剪强度大小最显著的因素是衬砌粗糙度,其次是环境温度和含水率,冻结时长的影响效应不显著,同时低温、低含水率、较长冻结时长、较高衬砌粗糙程度下的峰值抗剪强度越大。此项结果可为季节冻土区渠系工程防冻胀危害提供理论支撑。

关键词: 季节冻土区, 渠基土-衬砌接触面, 衬砌粗糙度, 峰值抗剪强度

Abstract:

Based on predecessors in the soil structure and the surface roughness affect the soil-structure of contact area between the tangential frost heaving force research is less, this study starts from the problem of tangential frost heaving force between soil-lining contact surfaces of canal foundation in western Sichuan seasonal frozen area, and focuses on the influence law and effect of surface roughness of lining on shear strength, cohesion and internal friction angle between contact surfaces. Combined with environmental temperature, moisture content and freezing time, the correlation and aboriginality of four factors on peak shear strength between contact surfaces are comprehensively explored by orthogonal analysis. The results show that the peak shear strength, cohesion and internal friction angle between the contact surfaces show the same law with the change of lining surface roughness, and the more rough the lining surface is, the three indexes will increase. The orthogonal analysis reveals that the most significant factor affecting the peak shear strength between the contact surfaces is the roughness of the lining, followed by environmental temperature and moisture content, and the effect of freezing time is not obvious. At the same time, the peak shear strength under low temperature, low moisture content, long freezing time and high roughness of the lining is larger. This result can provide theoretical support for the frost heaving hazard prevention of canal system engineering in seasonal frozen region.

Key words: seasonal frost area, channel foundation soil-lining interface, roughness of lining, peak shear strength

中图分类号:

  • P642.14
